Excellent quality Agriculture Drone Services Pricing - HZH JY30 Rescue Drone – Can Carry a Variety of Pods – Hongfei Detail:

HZH JY30 RESCUE DRONE DETAILS

HZH JY30 is a 6-wing transport supply drone with a maximum load of 30kg and a 70-minute endurance.
Equipped with newly designed high-performance motors, intelligent electronic governor and high-strength propellers, the drone provides weatherproof power support for various industrial applications with large load, high efficiency and excellent reliability.
Application scenarios: emergency rescue, firefighting lighting, crime fighting, material supply and other fields.

HZH JY30 RESCUE DRONE FEATURES

1. The fuselage adopts integrated carbon fiber design to ensure the rigid and high-strength product quality of the drone.

2. Maximum 70min no-load endurance.

3. Multi-functional applications, products are widely used in emergency rescue, firefighting lighting, crime fighting, material supply and other fields.

HZH JY30 RESCUE DRONE PARAMETERS

Material Carbon fiber + Aviation aluminum
Wheelbase 1980mm
Size 2080mm*1900mm*730mm
Folded size 890mm*920mm*730mm
Weight of empty machine 17.8KG
Maximum load weight 30KG
Endurance ≥ 70 minutes unladen
Wind resistance level 9
Protection level IP56
Cruising speed 0-20m/s
Operating voltage 61.6V
Battery capacity 30000mAh*2
Flight altitude ≥ 5000m
Operating temperature -30°to70°

HZH JY30 RESCUE DRONE DESIGN

HZH JY30 RESCUE DRONE

• Six-axis design, foldable fuselage, can carry 30 kg of weight, single 5 seconds to unfold or stow, 10 seconds to take off, flexible and highly maneuverable.
• Pods can be replaced quickly and can be loaded with multiple mission pods at the same time.
• Equipped with high-precision obstacle avoidance system (millimeter wave radar), in the complex urban environment, can monitor obstacles and avoid in real time (can identify the diameter of ≥ 2.5cm).
• Dual antenna dual-mode RTK accurate positioning up to centimeter level, with anti-countermeasures weapons interference capability.
• Industrial-grade flight control, multiple protection, stable and reliable flight.
• Remote real-time synchronization of data, images, site conditions, command center unified scheduling, management of UAV execution tasks.

HZH JY30 RESCUE DRONE APPLICATION

• The whole drone is compact and foldable to reduce the volume, and the high-strength carbon fiber and aviation aluminum ensure the safety of HZH JY30′s operation in harsh environments.

INTELLIGENT CONTROL OF HZH JY30 RESCUE DRONE

Intelligent Control  1

H12 Series Digital Fax Remote Control

H12 series digital map remote control adopts new surging processor, equipped with Android embedded system, using advanced SDR technology and super protocol stack to make image transmission clearer, lower latency, longer distance and stronger anti-interference. clearer, lower latency, longer distance and stronger anti-interference.

The H12 series remote control is equipped with dual-axis camera, supporting 1080P digital high-definition picture transmission; thanks to the product’s dual antenna design, the signals complement each other, and with the advanced frequency hopping algorithm, the communication capability of weak signals is greatly increased.

H12 remote control parameters
Operating voltage 4.2V
Frequency band 2.400-2.483GHZ
Size 272mm*183mm*94mm
Weight 0.53KG
Endurance 6-20 hours
Number of channels 12
RF power 20DB@CE/23DB@FCC
Frequency hopping New FHSS FM
Battery 10000mAh
Communication distance 10km
Charging interface TYPE-C
R16 receiver parameters
Operating voltage 7.2-72V
Size 76mm*59mm*11mm
Weight 0.09KG
Number of channels 16
RF power 20DB@CE/23DB@FCC



• 1080P digital HD image transmission: H12 series remote control with MIPI camera to achieve stable transmission of 1080P real-time digital HD video.

• Ultra-long transmission distance: H12 map-digital integrated link transmission up to 10km.

• Waterproof and dustproof design: Products in the body, control switches, the peripheral interfaces are made waterproof, dust-proof protection measures.

• Industrial-grade equipment protection: Weather silicone, frosted rubber, stainless steel, aviation aluminum alloy materials are used to develop, to ensure the safety of equipment.

• HD highlight display: 5.5-inch IPS display. 2000nits high brightness display, 1920 × 1200 resolution, large screen-to-body ratio.

• High performance lithium battery: Using high energy density lithium-ion battery, 18W fast charging, full charge can work for 6 ~ 20 hours.

Intelligent Control 2

Ground Station App

The ground station is heavily optimized based on QGC, with a better interactive interface and a larger map view available for control, dramatically improving the efficiency of UAVs performing tasks in specialized fields.

Intelligent Control 3

RESCUE DEVICE OF HZH JY30 RESCUE DRONE

STANDARD CONFIGURATION PODS OF HZH JY30 RESCUE DRONE

Standard-configuration-pod



Three-axis pods + crosshair aiming, dynamic monitoring, fine and smooth picture quality.



Operating voltage 12-25V
Maximum power 6W
Size 96mm*79mm*120mm
Pixel 12 million pixels
Lens focal length 14x zoom
Minimum focusing distance 10mm
Rotatable range tilt 100 degrees

Standard-configuration-pod-2
Standard-Configuration-Pod-3

INTELLIGENT CHARGING OF HZH JY30 RESCUE DRONE

Intelligent Charging



Charging power 2500W
Charging current 25A
Charging mode Precise charging, fast charging, battery maintenance
Protection function Leakage protection, high temperature protection
Battery capacity 30000mAh
Battery voltage 61.6V (4.4V/monolithic)

OPTIONAL CONFIGURATION OF HZH JY30 RESCUE DRONE

Optional configuration

For specific industries and scenarios such as electric power, firefighting, police, etc., carrying specific equipment to achieve the corresponding functions.

FAQ

1. What are the types of UAV operation methods?
Plant protection UAV: manual operation, fully autonomous operation, ab point operation
Industry UAV: mainly controlled by the ground station (remote control / suitcase base station)

2. What are the current product types of your company?
Agricultural plant protection uav, industry-level uav, according to your application scenarios to choose your suitable model.

3. The operation efficiency of drones?
Due to the differences in the series of products, refer to the product details

4. Uav flight time?
Because the UAV flies at full load for about 10 minutes, there is a little difference between the series, see which series of products you ask us, we can send specific detailed parameters to you.

5. Why do some batteries find less electricity after two weeks after being fully charged?
Smart battery has self-discharge function. In order to protect the battery’s own health, when the battery is not stored for a long time, the smart battery will execute self-discharge program, so that the power remains about 50% -60%
